40A 2 Pin Waterproof Cable Connector Plug And Socket For E Scooter

40A 2 Pin Waterproof Cable Connector Plug And Socket For E Scooter

  • 40A 2 Pin Waterproof Cable Connector Plug And Socket For E Scooter
40A 2 Pin Waterproof Cable Connector Plug And Socket For E Scooter
Product Details:
Place of Origin: Shenzhen,China
Brand Name: Jnicon
Certification: TUV,UL,CE,CQC
Model Number: M23
Payment & Shipping Terms:
Minimum Order Quantity: 1 pair
Price: Negotiable
Packaging Details: 1.Plastic bag;2.Carton;3.As per customer's requirements
Delivery Time: 3~5 working days
Payment Terms: T/T, Western Union, , D/P, D/A, L/C, MoneyGram
Supply Ability: 10000 sets / Day
Contact Now
Detailed Product Description
Current Rating: 40A Connecting Model: Push Lock
Contact Pin: 8PIN Voltage: 300V
Gender: Male,Other,male To Female,Male & Female Product Name: Male Female Wire Waterproof Connector,electronic Connectors
High Light:

E Scooter Waterproof Cable Connector


E Scooter Waterproof Plug Socket


40A Waterproof Plug Socket

40A 6Sqmm Cable 2Pin Power Waterproof connector Plug and Socket For E-Scooter

Description of 40A Power connector
Jnicon M23 model is specialized for E-Scooter. Its widely used in New Li-Lon battery E-Scooter. 50A high Current supported, and data transmission available in this design. Main thing is M23 connectors is updated with waterproof effection for E-Scooter.
Features:​ M23 Push Lock connectors

  • 2 power supply, 5IN signal 1pin grounding
  • IP67 rating
  • Voltage rating: 300V
  • Cable Range: 3~11mm
  • UL, TUV, CB, CCC, CE, RoHS approved
  • Mating cycle: 3000 times

Main characteristics Of Escooter waterproof connector

  • Sealed against dust and fluid (IP67)
  • power connector waterproof
  • Vibration resistance,impact resistance,stretching resistance
  • socket with cover
  • Cable assembly support
  • Customized cable size and length


Technical Parameters
Contact Resistance10 mΩ max
Insulation Structure500 MΩ at 500VDC
Operating Temperature-40°C ~ +105°C
IP ClassIP67 (1m / 30min)
Mold MaterialPA66
Contact/Terminal MaterialGold Plated Brass
Seal MaterialSilicone


Operation Parameters
Voltage Rating500VAC max
Min Wire Size OD3.0mm ~ 6.5mm
Max Wire Size OD6.5mm ~ 10mm
Max.Cable Cross Section Area0.3mm2 ~ 2.5mm2

Application of 2 pin power Waterproof connector Plug

  • inkjet systems
  • Solar System
  • industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic&pathology equipment
  • Communications equipment
  • Heavy machinery
  • Lithium-Ion Systems
  • Communications Application
  • product coding machines
  • inventory product coding

Advantage Of Waterproof Circular Connectors
Waterproof Connector is simply disassembled and assembled by locking the tail nut, so that the connector and the cable form a perfect fit, not easy to fall off, and its waterproof effect can achieve to IP67.
● good performance: use standard super five pure copper four stranded double wire and crystal head
● easy connection: no welding work, no installation tools, the standard crystal head can be directly inserted, can achieve rapid installation and use.
● waterproof and dustproof meet the requirements of IP67 standard.
● threaded connection, safe and reliable, impact, vibration, tensile
● anti-electromagnetic interference protection
●since the plug and socket do not need to break or interrupt any of the original wiring structure, there is no signal attenuation.
● miniaturization, saving installation space features
● convert existing Ethernet connectors into dust-proof, waterproof, fast connection/separation, and efficient cable assembly for normal operation and use in harsh environments.
1. Q: What type waterproof connector do you have?
A: We have 17series type connector,and make more than 3000types waterproof connector cable.Most of our connector is customized.We foucs on LED Waterproof connector,Assembly waterproof connector,Over-mold waterproof connector,T waterproof connector,Y customized waterproof connector.
2. Q: How to buy your products?
A: You need to do as followings:
* Confirm Current Rating and Number of Contacts
* Confirm Assembly style
* Confirm Cable Wire guage
* Confirm Cable Length and shipping way
3. Q: How to contact with you?
A: Please give us email,we have worked for this industry more than 10 years,So we can catch your problem,and solve it in a short time.if you have any question please feel free to let us know.
