| Place of Origin: | Shenzhen China |
| Brand Name: | Jnicon |
| Certification: | UL,TUV,CE,ROHS,CQC |
| Model Number: | M19 |
| Minimum Order Quantity: | 100 (10 Pairs of samples) |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1.Plastic bag;2.Carton;3.As per customer's requirements |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000/days |
| Model Number: | M19 Screw Locking Panel Connector | Connector Type: | Panel Mount Waterproof Connector |
|---|---|---|---|
| Waterproof Level: | IP68 | Rated Current: | 20A/300V |
| Cable Spec: | 16-12AWG | Application: | For Led Lighting,industrial Robot, Etc |
| Highlight: | M19 Waterproof Power Connector,IP67 Landscape Lighting Connectors,Screw Locking Landscape Lighting Connectors |
||
Screw Locking 3 Pin Waterproof Power Connector , IP67 Landscape Light Connector
Main Features :
M19 3 pin screw locking waterproof connector is fully achieved IP68 waterproof level, could be well used for underwater, underground applications, such pool lights, marine lights, fishing system, agriculture equipment.
Technical specification :
| Specifications: | |
| Connecting mode: | Screw locking waterproof connector |
| Core number: | 3 pin |
| Connector type : | Panel mount connector |
| Connector color: | Black, blue, yellow |
| Waterproof level: | IP68 |
| Cable specification: | 20AWG-12AWG |
| Cable diameter range: | 4.5mm-11mm |
| Contact diameter*No. | Φ1.0-Φ2.4 |
| Rated current (A): | 20A |
| Operating voltage (AC.V.rms): | 500V |
| Withstand voltage (AC.V)1min: | 1500V |
| Main characteristics: |
| Sealed against dust and fluid (IP67/IP68) |
| Vibration resistance, impact resistance, stretching resistance |
| Dust cover available |
Application Of Waterproof Circular Connectors
Our products are widely used in LED lighting, outdoor soft strip display, electrical equipment, automated robots, electric bicycles, ships, electric vehicles, etc.
How to use screw locking waterproof connector ?
This connector could be easy connection, convenient install, DIY tools, and no need to pinch-off cable electrical plastic sets, just unscrew the ends of waterproof connector, connect the wire correctly: N for Neutral wire, G for Ground wire, L for live wire.
