Shenzhen Jnicon Technology Co., Ltd.
Professional Waterproof Connectors Manufacturer
Sales & Support:
 |
| Place of Origin: | China |
| Brand Name: | Jnicon |
| Certification: | UL/CE/TUV/CQC/RoHS |
| Model Number: | Waterproof Panel Mount Connectors |
| Minimum Order Quantity: | 100 (10 Pairs of samples) |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1.Plastic bag; 2.Carton; 3.As per customer's requirement |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C,T/T,Paypal,Western Union |
| Supply Ability: | 10000pcs/day |
| Pin: | 8 | Certificates: | UL/CE/TUV/RoHS |
|---|---|---|---|
| Application: | Data Tansmission | Function: | Charging+Data Transfer With High Speed |
| Material: | PA66 | Gauge: | 24AWG |
| Highlight: | panel mount electrical connectors,panel mount power connector,Waterproof Panel Mount Electrical Connectors |
||
JNICON waterproof connector is male to female assembly connector with favorable waterproof level IP67.
It is suit for the outer diameter 5mm-9mm cable, its push fixing type is easy and safe for your outdoor operation.
Our waterproof connectors are widely applied in led, power, driver, controller, marine, electrical equipment, etc.
Product Features
Supportting customization
Series: pcb, straight, 8 pin row pin
Cable length and size are depends on you if you wanted
Cable series: cat5, cat6
Operating Parameters
| Signal socket | |
| Application | led display |
| Wistanding voltage | 500V |
| Isulation resistance | <60mΩ |
| Protection level | IP44/IP65 |
| Cable specification | 0.15-0.2mm2 |
| Connecting mode | Bayonet |
| Operating temperature | -25℃~80℃ |
| Shell | Zinc alloy |
| Copperneedles | Copper alloy |
| Flammability rating |
UL 94-V0 |
Our Services
1, We are the manufacture,JNICON is our brand, JNICON has built a great reputation in China even around the world.
2, We guaranteed that 100% in good quality, the price will be reasonal.
3, All the inquiry will be response within 24 hours, the commucation will be effective.
4, Special feature and service can be provided upon requirement.
FAQ
Q: Are you trading company or manufacturer ?
A:We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the goods are in stock. or it is 7-10 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Product Dimention
